NW35 NOWVEN® Double Dot Series High Temperature Adhesive Type[Interlining]

NW35

NOWVEN® Double Dot Series High Temperature Adhesive Type

ApparelX ID:1020138

This fusible interlining has excellent adhesive properties thanks to its double-dot resin processing.
It blends in well and brings out the best in the characteristics of the outer material.

Maker:

Supplier:

Color:Please select

Stock Status(*):Displayed after account registration

*Before taxes

Qty.

Inquiry About This Item

Color

Please select a color:

CH

Charcoal Heaven Gray

WH

White

Order Remarks

You can write a memo for the supplier, or yourself:

Enter Order Remarks

Item Description

This fusible interlining has excellent adhesive properties thanks to its double-dot resin processing.
It blends in well and brings out the best in the characteristics of the outer material.

Standard adhesive conditions Asahi JR600V

temperature	120~140℃
time	10-15 seconds
Cage Pressure	147~343kpa (1.5~3.5kgf/cm2)
Linear Pressure	12~33N/cm (1.2~3.3kgf/cm)

High temperature adhesive Asahi JR600V

temperature	140~145℃
time	10-15 seconds
Cage Pressure	147~343kpa (1.5~3.5kgf/cm2)
Linear Pressure	12~33N/cm (1.2~3.3kgf/cm)

The bonding conditions are the standard conditions for the bonding press. The optimum conditions may vary depending on the outer material, structure, etc., so please thoroughly check by conducting a bonding test with the same fabric before use.

Category	Interlining
Subcategory	Fusible Interlining
Gender	Unisex
Use Applications	General Purpose
Color Pattern	Plain
Tag	NEW


Specification	Standard: 150CM × 100M

Share This Item

FAQ

Regarding this item, there are the following FAQ:

What kind of trouble is glitter?

This is a phenomenon in which the resin can be seen glittering through the gaps in the surface material.
Low-density materials and dark-colored thin fabrics tend to stand out, so using colored resin can solve this problem.

What kind of trouble is Shimidashi?

The adhesive resin oozes out into the outer textile, which spoils the texture.
As a solution, choose a small shape adhesive resin.

What kind of trouble is fading?

The unevenness of the resin grains clearly appears on the surface of the outer textile. The solution is to choose a smaller resin interlining.

What does the D (denier) in 20D and 30D mean?

Denier is a unit used for filament thread(continuous long fiber)* and refers to the weight per 9000m. 1g at 9000m is 1 denier, and 50g is 50 denier.
The higher the denier, the thicker the thread and the thicker the fabric.

What is the difference between white, such as KW, fusible interlining, W, and Y, in the color of the fusible interfacing?

The color notation differs depending on the product number, but KW and W are fluorescent white, and Y and OW are off-white.
Fluorescent white is more pure white.

What kind of trouble is bubbling?

It looks like there are fine air bubbles between the outer textile and the interlining. The textile and the interlining are incompatible, so it is placed. If you choose a vertical or horizontal stretch interlining, it may be eliminated.

What is the difference between single-dot and double-dot fusible interlining interfacing?

The difference is the coating method of the adhesive.
A single dot is made by solidifying a fine powder adhesive and transferring it to the base fabric (base fabric) in dots.
Since the adhesive is fine, it does not fading out even on thin materials, and it is difficult to get hits.
Double Dot has a two-layer structure in which a gel-like adhesive is used as the base, and powdered adhesive is piled up on top of it.
High adhesive strength can be obtained for a wide range of materials.

How do I choose an interlining?

The interlining varies depending on the outer material, thickness, and location of use, so it is not possible to generalize.
Please let us know the material of the outer material, the parts to be used (neckline, body, etc.) and the desired texture from the inquiry form.

Also, if you provide the outer material, we can conduct an adhesion test. Please request from interlining adhesion test .
By performing an adhesion test, you can know in advance the adhesion strength and changes in appearance.
