JEC201W

JEC201W Lightweight Versatile Soft Interfacing 20D, Made With Recycled Materials Nittobo Advantex

JEC201W

Lightweight Versatile Soft Interfacing 20D, Made With Recycled Materials

ApparelX ID:1087666

This is a wide-width, standard-purpose stretch fusible interfacing made with 100% recycled polyester.
OMU2000 recycled polyester version.
Compared with ON42, it has slightly more body for a more masculine finish.
■Features
・Uses recycled polyester yarn for all base fabric.
・Compared with standard textured-yarn interfacing, performance such as hand feel and bonding strength is nearly equivalent. It is highly versatile and can be used for a wide range of items and outer fabrics.
・This interfacing uses Solution-Dyeing (dope-dyed yarn), and because there is no dyeing process, it is an environmentally friendly interfacing series that makes effective use of water and energy.
・A safe and reliable product certified by OEKO-TEX.

Brand / Manufacturer:Nittobo Advantex

Supplier:

OEKOTEX

Color:Please select

Stock Status(*):Displayed after account registration

*Excl. tax

Qty.

Ask About This Product

Color

Please select a color:

Black

White

Order Remarks

Add a note for the supplier or for your own reference:

Enter Order Remarks

Order Sample Book

Order a sample book here:

*Note: Sample Book Item will be added to your cart. Remove it from your cart if you do not need it. Your order notes will also be applied to the sample book.

SAMPLE

Sample Card

Product Description

Standard bonding conditions
・Flat type

Temperature	130~150℃
Time	10〜15 sec
Pressure (gauge pressure)	0.02〜0.03MPa(0.2〜0.3kgf/cm²)

・Roller type

Temperature	120~140℃
Time	10〜15 sec
Pressure (gauge pressure)	0.2〜0.3MPa(2.0〜3.0kgf/cm²)

■Suitable items
Body sections of jackets, blazers, and coats
Facings for blousons and bottoms, etc.
■Suitable materials
From lightweight materials such as blouses and dresses
For jacket materials: lightweight to heavyweight, natural to synthetic, etc.

Category	Interfacing
Subcategory	Fusible Interlining
Gender	Men's
Intended Use	General Purpose
Weave	Stretch
Color / Pattern	Solid
Style	JACKET, PANT
Collection	OEKOTEX


Specification	Specification: 152cm × 50m Thread: Warp 20d × Weft 20d
Material	100% polyester (100% recycled PET used) E
Brand / Manufacturer	Nittobo Advantex

Share This Item

FAQ

Frequently asked questions about this product:

What are the standard sizes for inside belt interfacing used in men's garments?

33 mm, 38 mm.

What kind of problem is kiratsuki?

It is the phenomenon of resin sparkling through the gaps in the weave of the face fabric.
Materials with a loose weave and dark-colored lightweight fabrics are especially noticeable, so using colored resin will resolve it.

What kind of problem is bleed-through?

A state where adhesive resin seeps through to the outer fabric, impairing the fabric’s hand.
As a solution, choose one with a smaller adhesive resin particle size.

What does the D (denier) in 20D or 30D mean?

Denier is a unit used for filament yarn (continuous filament fiber)*, indicating the weight per 9,000 m. If 9,000 m weighs 1 g, it is 1 denier; if it weighs 50 g, it is 50 denier.
The higher the denier count, the thicker the thread and the heavier the fabric.

What kind of problem is bubbling?

A condition where fine air bubbles appear to be trapped between the outer fabric and interlining. It occurs because the compatibility between the fabric and interlining is poor. It may be resolved by choosing an interlining with vertical and horizontal stretch.

What kind of problem is fading?

It is when the uneven texture of the resin pellets becomes clearly visible on the surface of the outer textile. The solution is to choose interfacing with smaller resin dots.

What is the difference between single-dot and double-dot fusible interlining?

It is a difference in the adhesive coating method.
Single dot is made by solidifying fine powdered adhesive and transferring it in a dotted pattern onto the base fabric.
Because the adhesive is fine, it is less likely to bleed through thin materials and less likely to cause fading.
Double dot has a two-layer structure, with a gel-like adhesive forming the base and powdered adhesive layered on top of it.
It provides strong adhesion for a wide range of materials.

What is the difference between the whites such as KW, OW, W, and Y in fusible interlining colors?

The color notation varies by product number, but KW and W are fluorescent white, and Y and OW are off-white.
Fluorescent white is a whiter, purer white.

Can interfacing be shipped rolled on a tube?

Basically, orders of 5 m or more will be shipped wound on a tube.

How should I choose interfacing?

The appropriate interlining varies depending on the face fabric material, thickness, and area of use, so we cannot give a single answer.
Please contact us via inquiries with the face fabric material, area of use (neckline, body, etc.), and desired hand feel.

If you can provide the face fabric, we can perform an adhesion test. Please request this from Interlining Adhesion Test.
By performing an adhesion test, you can find out in advance things like adhesive strength and changes in appearance.
