General-Purpose Processed Yarn Interlining, Volume Hard Type

ApparelX ID:1089677

1. Stretch in both the warp and weft directions provides excellent conformity.
2. The satin type creates a voluminous look.
3. The 122 cm wide-width specification allows for efficient pattern layout.

Brand / Manufacturer:Nittobo Advantex

Supplier:

Color:Please select

Stock Status(*):Displayed after account registration

*Excl. tax

Qty.

Ask About This Product

Color

Please select a color:

Black

Order Remarks

Add a note for the supplier or for your own reference:

Enter Order Remarks

Order Sample Book

Order a sample book here:

*Note: Sample Book Item will be added to your cart. Remove it from your cart if you do not need it. Your order notes will also be applied to the sample book.

SAMPLE

Sample Card

Product Description

1. Stretch in both the warp and weft directions provides excellent conformity.
2. The satin type creates a voluminous look.
3. The 122 cm wide-width specification allows for efficient pattern layout.

Press conditions
・Flat press type

Temperature	130~150°C
Time	10〜12 seconds
Pressure	0.03MPa(0.2〜0.3kgf/cm²)

・Roller press type

Temperature	120〜140°C
Time	10〜12 seconds
Pressure	0.2MPa(2.0〜3.0kgf/cm²)

* Press conditions vary depending on the press machine, so we recommend testing on a sample each time before use.

Product number	ON40	ON41	ON42	ON43	ON45
Product name	Lightweight soft interfacing for coat materials 20D	Soft interfacing 15D for preventing fading, bleed-through, and moiré	General-purpose interfacing for heavy garments (20D)	General-purpose interfacing for heavy garments (30D)	General-purpose interfacing for heavy garments (50D)
Thumbnail
Thickness order	2	1	2	3	4
Thickness	Thick	Thin	Thin to medium	Medium to thick	Medium to thick
Use	Front/facing/parts for jackets and coats	Facing, collar, and cuffs for blouses, shirts, and dresses	Jackets/blousons/coats	Jackets/blousons/coats	Jackets/blousons/coats
Suitable materials	Coarse fabrics, animal fiber and spun-wool fabrics, medium-weight jacket materials	Natural to synthetic, all kinds of lightweight materials	Natural to blended, all kinds of lightweight materials	Natural to blended, all kinds of lightweight materials	Natural to blended, all kinds of lightweight materials

* Horizontal scrolling is possible.

* The above information is for reference only. When using the product, please check the actual item.

Category	Interfacing
Subcategory	Fusible Interlining
Gender	Women's
Intended Use	Knits, Bottoms
Weave	Taffeta
Color / Pattern	Solid
Style	FORMAL, JACKET, KNIT, OUTDOOR, OUTER, PANT, SKIRT


Specification	Specification: 122cm x 50m Adhesive type: Polyamide double dot Suitable items: Jackets, suits, coats Compatible materials: Natural materials to blended, synthetic materials
Material	polyester E
Brand / Manufacturer	Nittobo Advantex

Share This Item

FAQ

Frequently asked questions about this product:

What are the standard sizes for inside belt interfacing used in men's garments?

33 mm, 38 mm.

What kind of problem is kiratsuki?

It is the phenomenon of resin sparkling through the gaps in the weave of the face fabric.
Materials with a loose weave and dark-colored lightweight fabrics are especially noticeable, so using colored resin will resolve it.

What kind of problem is bleed-through?

A state where adhesive resin seeps through to the outer fabric, impairing the fabric’s hand.
As a solution, choose one with a smaller adhesive resin particle size.

What does the D (denier) in 20D or 30D mean?

Denier is a unit used for filament yarn (continuous filament fiber)*, indicating the weight per 9,000 m. If 9,000 m weighs 1 g, it is 1 denier; if it weighs 50 g, it is 50 denier.
The higher the denier count, the thicker the thread and the heavier the fabric.

What kind of problem is bubbling?

A condition where fine air bubbles appear to be trapped between the outer fabric and interlining. It occurs because the compatibility between the fabric and interlining is poor. It may be resolved by choosing an interlining with vertical and horizontal stretch.

What kind of problem is fading?

It is when the uneven texture of the resin pellets becomes clearly visible on the surface of the outer textile. The solution is to choose interfacing with smaller resin dots.

What is the difference between single-dot and double-dot fusible interlining?

It is a difference in the adhesive coating method.
Single dot is made by solidifying fine powdered adhesive and transferring it in a dotted pattern onto the base fabric.
Because the adhesive is fine, it is less likely to bleed through thin materials and less likely to cause fading.
Double dot has a two-layer structure, with a gel-like adhesive forming the base and powdered adhesive layered on top of it.
It provides strong adhesion for a wide range of materials.

What is the difference between the whites such as KW, OW, W, and Y in fusible interlining colors?

The color notation varies by product number, but KW and W are fluorescent white, and Y and OW are off-white.
Fluorescent white is a whiter, purer white.

Can interfacing be shipped rolled on a tube?

Basically, orders of 5 m or more will be shipped wound on a tube.

How should I choose interfacing?

The appropriate interlining varies depending on the face fabric material, thickness, and area of use, so we cannot give a single answer.
Please contact us via inquiries with the face fabric material, area of use (neckline, body, etc.), and desired hand feel.

If you can provide the face fabric, we can perform an adhesion test. Please request this from Interlining Adhesion Test.
By performing an adhesion test, you can find out in advance things like adhesive strength and changes in appearance.
